Venturi Scrubber



Venturi Scrubber

Venturi Scrubber (Glass) is a device which affords intimate mixing of liquid and gas thereby achieving purpose of scrubbing/absorption. The advantages of ATR systems is easy operation, no moving parts, less maintenance costs, ability to handle large gas flow rates , intimate mixing, compact, less space, installed on tank, creates vacuum. Venturi scrubber is also very effective in removing dust particles from the gas. Where higher removal efficiencies are required multi stage venture scrubbers can be used. Substantial heat is generated during absorption. Suitable heat exchangers have to be installed in the system.

The most efficient and suitable equipment for this purpose is Falling Film Absorber. This equipment can do dual job of absorption as well as removal of heat of absorption. The venture scrubber then act like second stage scrubber and also imparts draft (negative pressure). Venturi Scrubber can also be incorporated with packed column absorber as second stage scrubber. With glass venture scrubber, a system can always be designed to meet any stringent Pollution Control Board norms for air quality.

Applications

  • Gas Absorption
  • Gas Liquid Reactions.
  • Imparting of Vacuum.
  • Fume Scrubber (low capacities).
  • Aeration.
  • Dust Collection/Air Pollution.
  • Creation of negative draft while feeding solids in the reactor during process.
  • Capacity: Individual off- the-shelf units are available in 4 sizes. Gas suction capacity

0-50 m3/h, 50-100 m3/h, 100-150 m3/h

Negative pressure created normally is 150 mm Hg. Special design scrubbers for higher capacities and or higher negative pressure are also available. Glass Venturies for applications other than absorption can also be designed. Complete turn-key plants incorporating Venturi Scrubbers are engineered and supplied by ATR Glass.
